Australia Semi-Cassette Awning

Australia Semi-Cassette Awning

The Australia Semi-Cassette Folding arm awning, building on the base frame of the Australia open-body awning, the semi-cassette has a modern styled heavy duty extruded hood and matching front bar to give a more aesthetic pleasing finish when retracted. It still retains the option to be able to adjust the angle of the awning using the pitch adjusters on the arm brackets.

Features

• Awning Width from 1.95m – 7m
• Heavy Duty Arms with Stainless Steel Chain
• Arm Sizes 1600mm, 2100mm, 2600mm, 3100mm & 3600mm
• Modern Styled Heavy Extruded 2-piece Aluminium Hood and Hood Brackets with Wide Front Bar
• 70mm Galvanized Roller Tube with Welded Seam for extra strength for awnings up to 5000mm
• 78mm Galvanized Roller Tube with Welded Seam for extra strength for awnings over 5000mm
• 40mm x 40mm Square Bar
• Manual or motorised operation is available
• 7:1 Gearbox is standard for manual awnings
• Awnings over 6m should be motorised
• Customer adjustable pitch control on each arm is an optional extra – Adjustment range 5 degrees to 60 degrees
• Optional Integrated Arms with LED Lighting.  Available in 2.6m, 3.1m and 3.6m projection. Kit price includes 120w 12v transformer, LED Strip ip64 5000k, connectors and wiring.   Only available for 2 arm awnings.

Colour Options

The BAT Australia Semi-Cassette standard frame colour options are White, Ivory, Silver Grey and Anthracite Texture.  Other Dulux Duralloy standard or Interpon Texture standard powder-coat colours are available at an additional cost.

Wind Rating

Wind Class 2 (European)/Beaufort Force 5 (Australian).

Maximum wind speed 37kph.

Specifications

Width 1.95m ↔ 7.04m (including hood)

Projection 1.6m, 2.1m, 2.6m, 3.1m & 3.6m

The BAT Australia Semi-Cassette is assembled here in Melbourne from components by BAT Italy and supplied by Global Awnings. Coolabah Shades custom make the fabrics from a wide range of available colours to suit your requirements.

You can download the brochure HERE

More images of awnings and other products are available in our GALLERY
